ProductCart <-> StoneEdge Integration User Guide |
|
StoneEdge Order Manager is an order management system that can help ProductCart users better manage orders when the ProductCart Control Panel is "not enough". For example, StoneEdge allows you to consolidate order management across different sales channels: phone orders, fax orders, Internet orders, etc. It can also assist you in a scenario where you are running multiple Internet storefronts.
To use the StoneEdge Order Manager with your ProductCart store, follow these instructions.
Add the new files
Contact Early Impact to obtain the latest StoneEdge integration files for your ProductCart store. Unzip the files that you obtained from Early Impact.
Locate the correct folder (Parent Paths Enabled or Parent Paths Disabled) based on your server settings.
Upload the files to their corresponding ProductCart folders. Remember that the ”pcadmin” folder has very likely been renamed on your store. Therefore, make sure to rename it on your desktop before you begin the FTP transfer, or else your FTP software will create a new ”pcadmin” folder on the Web server.
Update the database
To update your store database, follow these steps:
Log into your ProductCart Control Panel.
Replace the file name ”menu.asp” in the browser address field with ”upddb_STI.asp” and hit the ”Enter” key on your keyboard.
Configure your StoneEdge settings
Log into your ProductCart Control Panel
Replace the file name ”menu.asp” with ”StoneEdgeManager.asp”
Bookmark this page in your browser so that you can quickly go back to it if you need to
Fill out the required fields on the page:
Turn on the service
Enter a Cart ID/Username. It can be anything.
Enter a Cart Password. It can be anything.
Enter your Store Code: enter a numeric code to identify this store. This is used to handle a scenario in which you could have multiple ProductCart-powered storefronts and download orders into StoneEdge from all of them.
Write down the values used on this page because you will need them to setup StoneEdge Order Manager to communicate with ProductCart. The values must exactly match in both applications for the two systems to communicate successfully.
Follow these instructions to configure your StoneEdge Order Manager so that it can exchange information with your ProductCart store.
Open the Shopping Carts dialog box by one of three ways:
Main Menu> Maintenance Menu> Cart Functions tab> Create/Edit Shopping Carts > Go
Quick Clicks> Create/Edit Shopping Cart link
Quick Clicks> Setup Wizard> Shopping Carts link> Create and Edit Shopping Carts button
The Shopping Carts dialog box opens:
Click Add Cart.
Enter a Store Name.
Note: You can name the store anything you wish as long as it is easily distinguishable from other shopping carts you may have.
Click on the Cart Type drop down list and select ProductCart. Note: If you are licensed to use only one type of shopping cart you do not see a drop down list; ProductCart is your default cart type.
Enter your Cart ID/User Name. This is the user name that you entered in the ProductCart Control Panel on the StoneEdge Manager page. (Step 3.d.ii, in the previous section)
Enter your Cart Password. This is the password that you entered in the ProductCart Control Panel on the StoneEdge Manager page. (Step 3.d.iii, in the previous section)
Enter your Script URL. The URL will be: http://www.yourstore.com/productcart/sti/gateway.asp
i. Replace ”yourstore.com” with your domain name.
ii. Replace ”productcart” with the name you have given to the ProductCart folder, in case you have renamed it.
iii. The rest of the URL remains the same.
Enter your Store Code. (Step 3.d.iv, in the previous section)
Note: The remaining fields on the Shopping Carts screen are left blank.
Created 5/2/08
Updated 2/15/10
Modified: 10/25/10
